Syntax Safe tunnels signal crosstalk shielding and noise protection

Reciprocal interference and noise protection

Introducing the Syntax Safe Tunnels, a revolutionary shielding model.

Reciprocal interference and noise protection

Introducing the Syntax Safe Tunnels, a revolutionary shielding model.

Find out how we invented a powerful set of solutions to protect your data transmission from crosstalk between signals and from external noise.

  • A Safe place for signals

    A Safe place for signals

    Protecting what is most valuable

    Protecting what is most valuable

    The main purpose of an effective shielding solution is to protect all signals from interferences. External noise is a common issue on connectors and must be addressed properly. In a hybrid, modular, feature-rich connector as Syntax® SGH is, the main challenge is to prevent any crosstalk interference between signal conductors running close to each other. That's why we came up with an innovative design that not only solves problems related to interferences, it also allows quick wiring operations.

    Syntax SGH connector shielding from noise and crosstalk
  • Syntax Safe Tunnels

    Syntax Safe Tunnels

    Syntax Safe tunnels SGH crosstalk protection

    Every core element has several openings, one for each pair of signal conductors, leading to tunnels that cross the core through all its length. The Syntax Safe Tunnels play a decisive role in shielding our Syntax® SGH connectors from all internal and external interferences.

  • We preserved the integrity of the electrical signal by isolating it inside a tunnel

    We preserved the integrity of the electrical signal by isolating it
    inside a tunnel

  • Protection from external noise,
    insulation between signal conductors

    Protection from external noise,
    insulation between signal conductors

  • Network compliance: 10BASE-T, 100BASE-T, 1000BASE-T, 10GBASE-T

    Network compliance: 10BASE-T, 100BASE-T, 1000BASE-T, 10GBASE-T

  • Come with us

    Come with us

    Discover the highlights
    of a new philosophy of shielding

    Discover the highlights
    of a new philosophy of shielding

    In this section we want you to take a journey with us and discover all the elements that give life to a complex and ingenious shielding solution.

  • 1.   The issue: being free from interference

    1.
    The issue: being free from interference

    1.
    The issue: being free from interference

    Each of the twisted pairs that make up the signal conductors running inside the ethernet cables is mylar/aluminium foil shielded all along. However, a small portion of the mylar/aluminium foil must be removed to untwist the pairs, crimp the contacts, insert them in the corresponding modules and place the contact modules inside the core shell. Along that very short stretch of cable, with the pairs no longer twisted and their shield removed, it would be as if the wires were in the open, totally exposed to interferences. That’s exactly where the issue would arise…

  • 2.   Active core shielding

    2.
    Active core shielding

    2.
    Active core shielding

    The shell at the heart of the Syntax® SGH series is indeed the core of the system. Not only it is a precision-machined element housing the modules where the contacts are withheld; even more important than that is its function as an active component of the connector's shielding system.

  • 3.   Inside the tunnels

    3.
    Inside the tunnels

    3.
    Inside the tunnels

    The “no longer twisted” ethernet pairs, now crimped and locked in the contact modules, are channeled along the tunnels of the core element that serves as their housing.

  • 4.  Behind thick walls

    4.
    Behind thick walls

    4.
    Behind thick walls

    When modules and cables are in place, the thick inner walls of the Syntax Safe Tunnels provide a barrier against reciprocal interferences (crosstalk) between the pairs placed in each tunnel.

  • 5.   Sealing it all with a capsule

    5.
    Sealing it all with a capsule

    5.
    Sealing it all with a capsule

    The sensible areas shown at point 1, however, would still be partially exposed to reciprocal interferences, as the gaps in the slots allow easy access for the wires inside the tunnels to completely impede the shielding. A specifically designed capsule seals the slots on the outer side of the tunnels, creating an area totally free from crosstalk, reduced Next/Fext level.

    Thanks to its conductive galvanic surface, the capsule is a double-purpose element also providing complete shield propagation from cable to cable through the mated SGH connectors.

  • 6.   The assembled structure

    6.
    The assembled structure

    6.
    The assembled structure

    When the capsule is in place and mated with a second connector, the complete shielding structure extends from the starting cable through the connector and onto the next connector to the destination cable.

  • It's as if your cables
    had never been interrupted!

    It's as if your cables
    had never been interrupted!
