SGH 8.1 inline

SGH 8.1 inline

Hybrid connectivity
as easy as it gets.
8 modules + power or signals

SGH 8.1 inline

Hybrid connectivity
as easy as it gets.
8 modules + power
or signals

Syntax® wireasy technology

  • Invention is a dirty job,
    but someone has to do it

    Invention is a dirty job, but someone has to do it

  • A solution designed for clean, interference-free signals on your connections

    A solution designed for clean, interference-free signals
    on your connections

    Syntax® Gigamod Hybrid, aka SGH is a groundbreaking innovation in the world of hybrid connections. It is a modular, adaptable solution providing versatile connections for multiple fields of application. Syntax® SGH allows simultaneous connectivity for power, controls, signaling and monitoring systems. The innovation of this technology is centered on a very simple idea: wiring and using this connector must be quick and easy for everyone. We did the dirty job, we invented a complex engineering solution and left the clean part for you - reliable, intuitive, easy-to-use circular connectors, suitable and easy to handle in any situation.

    A solution designed for clean, interference-free signals on your connections
  • Less is more

    Less is more

    Less complication and fewer cables, our pursuit of practicality

    Less complication and fewer cables,
    our pursuit of practicality

    Syntax® SGH 8.1 inline connectors have been designed with practicality for assemblers and users as the main goal. From the initial conception to the first draft stages and subsequent developments, our engineering team has pursued a practical solution where, thanks to our proprietary Syntax Wireasy technology, each component has been thoughtfully designed to make your work easier. Easier wiring without any special assembling tools needed. Easier cable management as everything you need will be on a single cable. Syntax® SGH is professionalism within everyone's reach.

    Less is more
  • Worried about wiring?

    Worried about wiring?

    Take it Wireasy

    Take it Wireasy

    SGH is designed to be quick

  • We know your time is valuable. That's why we made the SGH series with a special focus on assembling and wiring simplicity. Forget those complex procedures needed for other hybrid connectors. Our SGH has been designed for fastest and easiest assembling.

  • Available modules and contacts

    Available modules
    and contacts

    Explore the possibilities of a fully modular connector

    Explore the possibilities of a fully
    modular connector

    Add power or signals. A complete range of modules are currently available, and any of them can be fitted on any version of the SGH connectors series.

    Available modules and contacts
  • Use cases

    Use cases

    Syntax® SGH 8.1

    Syntax® SGH 8.1

    Use cases

    The best of all possible worlds
    All in one cable management with modules for Ethernet, HDMI, USB3 + Power or Signal

  • Application fields

    Application fields

  • The versatility of a fully hybrid and modular connector

    The versatility of a fully hybrid and modular connector

    The versatility of a fully hybrid
    and modular connector

    So many ways to improve your work

    So many ways to improve your work

    Imagine the limitless applications of a multimodule connector for Ethernet/HDMI/USB3 signals also carrying a central module for power or additional signals. Check out the application fields page for a few examples. And for more possibilities… no one knows your business like you do.

  • Syntax safe tunnels

    Syntax safe tunnels

    Protection from external noise
    Insulation between signal conductors

    Protection from external noise
    Insulation between signal conductors

    Syntax safe tunnels
  • Protection from external noise,
    insulation between signal conductors

    Protection from external noise,
    insulation between signal conductors

    The Syntax Safe Tunnels are the key elements creating a controlled environment inside the SGH connector, an interference-free area where the non-twisted pairs are channeled and kept free from interferences.

  • Shield propagation

    Shield propagation

    Discover the highlights of a new philosophy of shielding

    Discover the highlights of a new philosophy of shielding

    Shield propagation

    Discover all the elements that give shape to an ingenious shielding solution. A new philosophy for shield propagation from cable to cable, as if there were no connectors at all…

  • Exploded view

    Exploded view

    Exploded view
  • Metric cable glands

    Metric cable glands

    Metric cable glands

    for the multiway connectors

    for the multiway connectors

    Metric thread cable glands allow more versatility compared to PG or other thread types. All cable glands supplied with the Syntax Gigamod Hybrid connectors provide IP68 rating at the back of the connecotrs.

  • Metric cable glands

    Metric cable glands

    Metric cable glands

    Dimensions

    Dimensions


    V (thread size)ØS clamping range (for inline)KZL
    M 32 (for SGH 8.1 inline)18 - 25 mm46 mm10 mm52 mm
    M 40 oversize (for SGH 8.1 multiway and SGH 16.1 inline and multiway)22 - 32 mm46 mm10 mm52 mm

  • Available versions

    Available versions

    SGH 8.1 Multiway

    SGH 8.1 Multiway

  • With grommets for IP67 cable splitters

    With grommets for IP67 cable splitters

    The Syntax® proprietary multiway rubber grommets are directly fitted in the cable gland and guarantee optimal cable retention and IP67 watertight seal for outdoor use.

  • Overall dimensions

    Overall dimensions

  • Inline female

    Inline female

    Inline female

    SGH 8.1 | M32 cable gland for single cable

    SGH 8.1 | M32 cable gland for single cable

  • Inline male

    Inline male

    Inline male

    SGH 8.1 | M32 cable gland for single cable

    SGH 8.1 | M32 cable gland for single cable

  • Multiway female

    Multiway female

    Multiway female

    SGH 8.1 | M40 cable gland with multiway grommet for cable splitters

    SGH 8.1 | M40 cable gland with multiway grommet for cable splitters

  • Multiway male

    Multiway male

    Multiway male

    SGH 8.1 | M40 cable gland with multiway grommet for cable splitters

    SGH 8.1 | M40 cable gland with multiway grommet for cable splitters
