Syntax Hybrid cables for SGH series, signal and power

Syntax Hybrid Cables

for SGH connectors series

Syntax Hybrid Cables

for SGH connectors series

Flexible, easy to handle, all in one professional cables for almost limitless applications.
Robust and super easy for fast wiring.

  • Syntax Hybrid Cables with
    2 x Ethernet

    Syntax Hybrid Cables with
    2 x Ethernet

  • for SGH 8.1

    for SGH 8.1

  • 2 x CAT6A

    2 x CAT6A

    2 x CAT6A

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7XLAN2CAT6AUF cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The data signals are conveyed by two Cat6a cables having the same performances as our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle. Overall diameter 20 mm


    Part N.Diameter
    7XLAN2CAT6AUFě 20 mm

  • 2 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • Overall jacket
    MaterialPVC  flame-retardant
    Colormatt Black
    Diameterě=20 mm

  • 2 x CAT6A + 3G2.5 mm2

    2 x CAT6A + 3G2.5 mm2

    2 x CAT6A + 3G2.5 mm2

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7YLN2CAT6APW325G cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The power line is equipped with its own PVC jacket for added safety in compliance with the I.E.C. regulation. The data signals are conveyed by two Cat6a cables having the same performances of our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle.
    Overall diameter 21 mm


    Part N.Diameter
    7YLN2CAT6APW325Gě 21 mm

  • 2 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 1 x POWER
    Conductorsstranded OFC 3 x 1.5 mm▓ - 15 AWG
    Conductors jacketBrown, Blue, Green-Yellow PVC
    External jacketBlack PVC ě 7,6 mm flame-retardant


    Overall jacket
    MaterialPVC  flame-retardant
    Colormatt Black
    Diameterě=21 mm

  • 2 x CAT6A + 5G2.5 mm2

    2 x CAT6A + 5G2.5 mm2

    2 x CAT6A + 5G2.5 mm2

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7YLN2CAT6APW525 cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The data signals are conveyed by two Cat6a cables having the same performances as our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle. Overall diameter 20 mm


    Part N.Diameter
    7YLN2CAT6APW525ě 20 mm

  • 2 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 5 x POWER
    Conductorsstranded OFC 1.5 mm▓ - 15 AWG
    Conductors jacketBrown, Black, Gray, Blue, Green-Yellow PVC

    Overall jacket
    MaterialPVC flame-retardant
    Colormatt Black
    Diameterě=20 mm

  • 2 x CAT6A + 3G6 mm2

    2 x CAT6A + 3G6 mm2

    2 x CAT6A + 3G6 mm2

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7YLN2CAT6APW360 cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The data signals are conveyed by two Cat6a cables having the same performances as our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle. Overall diameter 20 mm


    Part N.Diameter
    7YLN2CAT6APW360ě 20 mm

  • 2 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 3 x POWER
    Conductorsstranded OFC 6 mm▓ - 10 AWG
    Conductors jacketBrown, Blue, Green-Yellow PVC

    Overall jacket
    MaterialPVC flame-retardant
    Colormatt Black
    Diameterě=20 mm

  • 2 x CAT6A + 4 digital

    2 x CAT6A + 4 digital

    2 x CAT6A + 4 digital

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The SYNTAX« 7YLN2CAT6ADG4 cable has the same specs as the 7XLANCAT6AUFPUR cable with the addition of 4-pair AES/EBU digital cables.
    Overall diameter 20 mm


    Part N.Diameter
    7YLN2CAT6ADG4ě 20 mm

  • 2 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 4 x DIGITAL
    Conductorstinned OFC 24 AWG - 28 x 0,10mm
    Conductors jacketwhite/blue gas injected foam ě 1,4mm
    Drain wiretinned OFC 24 AWG - 7 x 0,18mm
    Screenaluminium/mylar foil 100% cov.
    Nominal Impedence1-4 Mhz 110 Ω/100 mt
    External jacketBlack PVC flame-retardant ě 3,4mm
    D.C.R. conductors<86 Ω/Km
    D.C.R. shield<70 Ω/Km
    Capacitance cond./cond.1Khz 37 nF/Km
    Capacitance cond./shield1Khz 57 nF/Km


    External jacket
    MaterialPVC flame-retardant
    Colormatt Blue
    Diameterě 3,8 mm



    Overall jacket
    MaterialPVC flame-retardant
    Colormatt Black
    Diameterě=20 mm

  • Syntax Hybrid Cables with 4 x Ethernet

    Syntax Hybrid Cables with
    4 x Ethernet

  • for SGH 16.1

    for SGH 16.1

  • 4 x CAT6A

    4 x CAT6A

    4 x CAT6A

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7XLAN4CAT6AUF cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The data signals are conveyed by four Cat6a cables having the same performances as our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle. Overall diameter 23,5 mm


    Part N.Diameter
    7XLAN4CAT6AUFě 23,5 mm

  • 4 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • Overall jacket
    MaterialPVC  flame-retardant
    Colormatt Black
    Diameteě=23,5 mm

  • 4 x CAT6A + 5G2.5 mm2

    4 x CAT6A + 5G2.5 mm2

    4 x CAT6A + 5G2.5 mm2

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7YLN4CAT6APW525 cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The data signals are conveyed by four Cat6a cables having the same performances as our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle. Overall diameter 23,5 mm


    Part N.Diameter
    7YLN4CAT6APW525ě 23,5 mm

  • 4 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 5 x POWER
    Conductorsstranded OFC 2.5 mm▓ - 15 AWG
    Conductors jacketBrown, Black, Gray, Blue, Green-Yellow PVC


    Overall jacket
    MaterialPVC flame-retardant
    Colormatt Black
    Diameterě=23,5 mm

  • 4 x CAT6A + 3G6 mm2

    4 x CAT6A + 3G6 mm2

    4 x CAT6A + 3G6 mm2

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The combined Syntax« 7YLN4CAT6APW360 cable finds its main application in the digital signage field, whenever clean, easy and fast cabling is required. The data signals are conveyed by four Cat6a cables having the same performances as our 7XLANCAT6AUFPUR cable, to ensure reliability in critical conditions. The external flame-retardant black PVC jacket is flexible, trampling-proof, impact absorbing and easy to handle. Overall diameter 25 mm


    Part N.Diameter
    7YLN4CAT6APW360ě 25 mm

  • 4 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 3 x POWER
    Conductorsstranded OFC 6 mm▓ - 10 AWG
    Conductors jacketBrown, Blue, Green-Yellow PVC

    Overall jacket
    MaterialPVC flame-retardant
    Colormatt Black
    Diameterě=25 mm

  • 4 CAT6A + 4 digital

    4 CAT6A + 4 digital

    4 CAT6A + 4 digital

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The SYNTAX« 7YLN4CAT6ADG4 cable has the same specs as the 7XLANCAT6AUFPUR cable with the addition of 4-pair AES/EBU digital cables.
    Overall diameter 24 mm


    Part N.Diameter
    7YLN4CAT6ADG4ě 24 mm

  • 4 x CAT6A
    Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    Conductors jacketPolyolefin Skin Foam - ě=1,25 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 76%
    JacketBlack PVC ě 8,3 mm flame-retardant


  • 4 x DIGITAL
    Conductorstinned OFC 24 AWG - 28 x 0,10mm
    Conductors jacketwhite/blue gas injected foam ě 1,4mm
    Drain wiretinned OFC 24 AWG - 7 x 0,18mm
    Screenaluminium/mylar foil 100% cov.
    Nominal Impedence1-4 Mhz 110 Ω/100 mt
    External jacketBlack PVC flame-retardant ě 3,4mm
    D.C.R. conductors<86 Ω/Km
    D.C.R. shield<70 Ω/Km
    Capacitance cond./cond.1Khz 37 nF/Km
    Capacitance cond./shield1Khz 57 nF/Km


    External jacket
    MaterialPVC flame-retardant
    Colormatt Blue
    Diameterě 3,8 mm


    Overall jacket
    MaterialPVC flame-retardant
    Colormatt Black
    Diameterě=24 mm

  • Main Power cable 16A

    Main Power cable 16A

    Main Power cable 16A

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The main application of the SYNTAX« MAINFLEX cable is in lighting technology and other current-carrying circuits. The strand construction has been designed to get the best flexibility with a wide range of external temperatures. This cable has good impact absorbing properties and the external jacket is compliant with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 regulations.The 11.3 mm overall diameter is indended to grant IP67 protection when the cable is used with the 6-way rubber grommet of our SYNTAX SSX 19 pin Spider connector, for break-in and break-out leads.


    Part N.Diameter
    7ZF0325ě 11,3 mm

  • Conductorsstranded OFC 3 x 2.5 mm2
    Resistance of conductorsIEC 60344
    Insulation resistance> 200 MΩ/Km
    Operating Voltage450/750 V
    Color codeBrown-Blue-Green/Yellow


  • Overall jacket
    JacketBlack matt PVC flame retardant
    Temperature range-30░C +70░C
    Diameterě=11.3 mm

  • Main Power cable 32A

    Main Power cable 32A

    Main Power cable 32A

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The main application of the SYNTAX« MAINFLEX cable is in lighting technology and other current-carrying circuits. The strand construction has been designed to get the best flexibility with a wide range of external temperatures. This cable has good impact absorbing properties and the external jacket is compliant with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 regulations.The 14 mm overall diameter is indended to grant IP67 protection when the cable is used with the 6-way rubber grommet of our SYNTAX SSX 19 pin Spider connector, for break-in and break-out leads.


    Part N.Diameter
    7ZF0360ě 14 mm

  • Conductorsstranded OFC 3 x 6 mm2
    Resistance of conductorsIEC 60344
    Insulation resistance> 200 MΩ/Km
    Operating Voltage450/750 V
    Color codeBrown-Blue-Green/Yellow

  • Overall jacket
    JacketBlack matt PVC flame retardant
    Temperature range-30░C +70░C
    Diameterě=14 mm

  • Main Power Cable 3p+N+E (4p 5w)

    Main Power Cable 3p+N+E (4p 5w)

    Main Power Cable
    3p+N+E (4p 5w)

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The main application of the SYNTAX« MAINFLEX cable is in lighting technology and other current-carrying circuits. The strand construction has been designed to get the best flexibility with a wide range of external temperatures. This cable has good impact absorbing properties and the external jacket is compliant with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 regulations. The 12.5 mm overall diameter is indended to grant IP67 protection when the cable is used with the 6-way rubber grommet of our SYNTAX SSX 19 pin Spider connector, for break-in and break-out leads.


    Part N.Diameter
    7ZF0525ě 12.5 mm

  • Conductorsstranded OFC 5 x 2.5 mm2
    Resistance of conductorsIEC 60344
    Insulation resistance> 200 MΩ/Km
    Operating Voltage450/750 V
    Color codeBrown-Black-Gray-Blue-Green/Yellow

  • Overall jacket
    JacketBlack matt PVC flame retardant
    Temperature range-30░C +70░C
    Diameterě=12.5 mm

  • Syntax Breakout Cables

    Syntax Breakout Cables

  • for SGH series

    for SGH series

  • Ethernet CAT6A

    Ethernet CAT6A

    Ethernet CAT6A

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    The SYNTAX« 7XLANCAT6AUFPUR Cat6 cable is designed for mobile use in broadcasting and in all Class 6A network installations with transmission frequency up to 500MHz; it is compliant with ISO/IEC 11801 - EN 50173 - EIA/TIA 568B.2 and ensures accurate transmission of data up to 90 meter cable stretches. The outer polyurethane (PUR) sheath has been particularly designed for rigorous conditions in outdoor applications, for use on cable drum, for mobile media vehicles and wherever high abrasion resistance and continuous bending cycles are needed, preserving enduring transmission quality.


    Part N.Diameter
    7XLANCAT6AUFPURě 8.2 mm


  • Stranding8 cores twisted in 4 pair
    ConductorsSolid bare OFC ě=0,57mm - 23 AWG
    InsulationPolyolefin Skin Foam - ě=1,24 ▒ 0,01 mm
    Color codeComply EIA/TIA 568
    ScreenFTP aluminium-polyester tape 100% cov.
    DC loop resistancemax 145 Ω/Km 20░C
    Insulation resistancemin 5 GΩ x Km
    Test voltageAC 50 Hz: 700V - DC: 1000V
    Capacity between conductors45 ▒ 5 nF/Km at 1 kHz
    Characteristic impedance100 ▒ 5 Ω
    NVP value≥ 77.5%


  • Overall jacket
    MaterialPVC  flame-retardant
    Colormatt Black
    Diameterě=8,2 mm -0,5/+0,2mm

  • Single pair digital

    Single pair digital

    Single pair digital

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    Syntax« single pair Digital AES/EBU-DMX cable, (standard AES/EBU and DMX use specifications) is manufactured with reliably consistent impedance and features a special polymer sheath for low capacitance. To ensure a high protection level from EMI/RFI noise, the shield is made up of two different shields:
    ● the first is a high-density spiral tinned copper;
    ● the second is a aluminium/polyester foil.
    The drain wire between the two screens makes connection easier. Black or Blue PVC flame-retardant external jacket, trampling-proof, impact absorbing and flexible for longer lifespan.


  • Conductorstinned OFC 24 AWG - 28x0,10 mm
    Conductors jacketred/blue Foam Skin ě 1,4 mm
    Drain wiretinned OFC 24 AWG - 19x0,12 mm
    Screen 1high density spiral tinned OFC 95% cov.
    Screen 2aluminium/polyester foil 100% cov.
    Operating temperature-30░ +70░ C.
    External jacketPVC ě 5,5 mm flame-retardant, Blue (7XDDS03SX), Black (7XDDS03SXN)


  • D.C.R. conductors<90 Ω/KmD.C.R. shield: <40 Ω/Km
    Capacitance cond./cond.1Khz 40 nF/Km
    Capacitance cond./shield1Khz 80 nF/Km
    Nominal Impedence1-4 Mhz 110 Ω/100 mt


    Part N.DiameterColor
    7XDDS03SXě 5,5 mmBlue
    7XDDS03SXNě 5,5 mmBlack

  • Single pair digital - Halogen free

    Single pair digital - Halogen free

    Single pair digital - Halogen free

    for Syntax Gigamod Hybrid

    for Syntax Gigamod Hybrid

    Syntax« single pair Digital AES/EBU-DMX cable, (standard AES/EBU and DMX use specifications) is manufactured with reliably consistent impedance and features a special polymer sheath for low capacitance. To ensure a high protection level from EMI/RFI noise, the shield is made up of two different shields:
    ● the first is a high-density spiral tinned copper;
    ● the second is a aluminium/polyester foil.
    The drain wire between the two screens makes connection easier. Dark green flame-retardant LSZH halogen free external jacket, trampling-proof, impact absorbing and flexible for longer lifespan.


  • Conductorstinned OFC 24 AWG - 28x0,10 mm
    Conductors jacketred/blue Foam Skin ě 1,4 mm
    Drain wiretinned OFC 24 AWG - 19x0,12 mm
    Screen 1high density spiral tinned OFC 95% cov.
    Screen 2aluminium/polyester foil 100% cov.
    Operating temperature-30░ +70░ C.
    External jacketě 5,5 mm LSZH halogen free, Green (7XDDHF03SX)


  • D.C.R. conductors<90 Ω/KmD.C.R. shield: <40 Ω/Km
    Capacitance cond./cond.1Khz 40 nF/Km
    Capacitance cond./shield1Khz 80 nF/Km
    Nominal Impedence1-4 Mhz 110 Ω/100 mt


    Part N.Diameter
    7XDDHFS03SXě 5,5 mm
