Syntax Gigamod Hybrid 16.1 modular panel connector

SGH 16.1 panel

Take your hybrid connections
to the next level.

16 modules + power or signals

SGH 16.1 panel

Take your hybrid connections
to the next level.

16 modules + power
or signals

Syntax® Wireasy technology

  • How about a perforated backshell for SGH 16.1 panels?

    Double the signals, halve the strain on the wiring

    Double the signals,
    halve the strain on the wiring

    How about a perforated backshell
    for SGH 16.1 panels?

  • Syntax® SGH is in many ways a flagship Syntax product. It has undoubtedly the form and size of a simple connector, but more than that it is a multiconnectivity device concealed in a heavy duty shell, a quick-connection tool containing as many as 16 contact pair modules for signals plus a central insert for power up to 32amp or up to 4 additional signal channels. SGH 16.1 is a real showcase of our engineering capabilities, a heavy duty product that raises the bar on the future of multipurpose hybrid connections while ensuring the total reliability, high quality and perfect ergonomics every Syntax customer expects of our products. With the plus of Syntax Wireasy technology, that allows super-easy and fast wiring with no special assembling tools needed.


    Syntax SGH 16.1 signal modules, power insert and panel backshell
  • A perforated backshell
    for secure wiring

    2 parts, 1 system

    2 parts, 1 system

    A perforated backshell
    for secure wiring

    A proprietary system providing support and stability to cables. The perforated backshell of the SGH panel-mount connectors is designed to provide extra safety for the fastening of the wired cables. The cables are tied to the holes located around the circumference. This prevents damaging the internal components due to the weight of the cable.

  • Syntax multipin panel hybrid connector with backshell

    The two components making up the Syntax® Gigamod Hybrid panel-mount system are the SGH panel connector and the perforated backshell threaded to the flange of the connector itself . The particular design of the perforated backshell is an innovative yet simple feature that allows steady fastening of the wiring to the backshell through common cable ties. A simple and ingenious way to mechanically protect the cables and manage the internal wiring in an orderly fashion, providing added cable strain relief and preventing the risk of electrical damage as a consequence.

  • panel connector backshell detail

    Front view

    Front view

    Backshell with cables

    Backshell with cables

  • panel connector backshell detail

    Rear view

    Rear view

    Backshell with cables

    Backshell with cables

  • Worried about wiring?

    Worried about wiring?

    Take it Wireasy

    Take it Wireasy

    SGH is designed to be quick

  • We know your time is valuable. That's why we made the SGH series with a special focus on assembling and wiring simplicity. Forget those complex procedures needed for other hybrid connectors. Our SGH has been designed for fast and easy assembling.

  • Available modules and contacts

    Available modules
    and contacts

    Explore the possibilities of a fully modular connector

    Explore the possibilities of a fully
    modular connector

    Add power or signals. A complete range of modules are currently available, and any of them can be fitted on any version of the SGH connectors series.

    Available modules and contacts
  • Use cases

    Use cases

    Syntax® SGH 16.1

    Syntax® SGH 16.1

    Use cases

    The best of all possible worlds
    All in one cable management with modules for Ethernet, HDMI, USB3 + Power or Signal

  • Application fields

    Application fields

  • The versatility of a fully hybrid and modular connector

    The versatility of a fully hybrid and modular connector

    The versatility of a fully hybrid
    and modular connector

    So many ways to improve your work

    So many ways to improve your work

    Imagine the limitless applications of a multimodule connector for Lan/HDMI/USB3 signals also carrying a central module for power or additional signals. Check out the application fields page for a few examples. And for more possibilities… no one knows your business like you do.

  • Syntax safe tunnels

    Syntax safe tunnels

    Protection from external noise
    Insulation between signal conductors

    Protection from external noise
    Insulation between signal conductors

    Syntax safe tunnels
  • Syntax safe tunnels crosstalk barrier
  • Protection from external noise,
    insulation between signal conductors

    Protection from external noise,
    insulation between signal conductors

    The Syntax Safe Tunnels are the key elements creating a controlled environment inside the SGH connector, an interference-free area where the non-twisted pairs are channeled and kept free from interferences.

  • Shield propagation

    Shield propagation

    Discover the highlights of a new philosophy of shielding

    Discover the highlights of a new
    philosophy of shielding

    Shield propagation

    Discover all the elements that give shape to an ingenious shielding solution. A new philosophy for shield propagation from cable to cable, as if there were no connectors at all…

  • Exploded view

    Exploded view

    Syntax SGH 16.1 panel modular hybrid connector exploded view
  • Syntax Gigamod Hybrid 16.1 panel rack Syntax Gigamod Hybrid 16.1 panel rack
  • The IP67 caps are supplied as a standard

    The IP67 caps are supplied as a standard

    Waterproof your connectors

    Waterproof your connectors

    The IP67 caps are supplied as a standard

    IP67 protection of the Syntax Gigamod Hybrid is fully ensured when all the connectors are mated or all the caps are fitted.

  • Overall dimensions

    Overall dimensions

  • Panel female

    Panel female

    Panel female

    SGH 16.1

    SGH 16.1

    Dimensions in mm

  • Panel male

    Panel male

    Panel male

    SGH 16.1

    SGH 16.1

    Dimensions in mm

  • Cut-out dimensions

    Cut-out dimensions

    Cut-out dimensions

    SGH 16.1

    SGH 16.1

    Dimensions in mm
